Twist Tester – Model: ILE-ITC-5-H

Hand operated twist tester, for plied and singles yarn, 0-20 inches and 0-50 centimeters.  For both S and Z Twist.  Battery activated lamp indicates proper tension and completed test for singles yarns. Counter power supply: specify 120 Vac, or 220 Vac, or battery pack.

Motorized Twist Tester – Model: ILE-ITC-5-M

Motor operated twist tester, for plied and singles yarn, 0-20 inches and 0-50 centimeters.  For both S and Z Twist. Battery activated lamp indicates proper tension and completed test for singles yarns.

Motorized Twist Tester – Model: ILE-ITC-5-M-100

Motor operated twist tester, for plied and singles yarn, 0-100 inches.  For both S and Z Twist. Battery activated lamp indicates proper tension and completed test for singles yarns.

Electronic Digital Twist Tester – Model: ILE-DE-5

Semi-Automatic testing of single or plied yarns. Digital displays of twist for sample length tested, as well as twist per unit selected (twist per inch, twist per centimeter). Automatically stops at end of test. Allows multiple test of same sample. Variable speed. Specify 110 or 220 volts, 50/60 Hz.

Digital Microprocessor Twist Tester – ILE-DTC-2000

Semi-Automatic testing of single or plied yarns. Digital displays of twist for sample length tested, as well as twist per unit selected (twist per inch, twist per centimeter). Automatically stops at end of test. Allows multiple test of same sample. Variable speed. Sample memory of groups or batch tests. Statistical data of multiple samples provided in addition to high, low, range, and average. Printer included.  Specify 110 or 220 volts, 50/60 Hz.

ILE-ITD-28 TWIST INSERTION

Twist Insertion Instrument.  For inserting various twists in yarns. 0-20 inches and 0-50 cm.

ILE-ITD-32S TWIST INSERTION

Designed to allow the inserting of various twists in yarns for research and development. Unit comes ready for 0-20 inch and 0-50 cm testing with bi-directional electronic counting in S or Z rotation. Pre-Set allows for exact duplication of samples.

Complete with extension for 0-50 inch or 0-160 cm samples. Standard tension weights included. 110V, 60 hz.

TIRE CORD WEIGHTS

ILE-CYA-300 Core Yarn Analyzer

Variable speed and tension controls allow unwrapping of core and elastic yarns with multiple layers.  Operates in both S and Z directions with counter for number of turns per unit length. 3-digit readout.  110/220 volts.

ILE-CYA 300-D Core Yarn Analyzer

Variable speed and tension controls allow unwrapping of core and elastic yarns with multiple layers.  Operates in both S and Z directions with counter for number of turns per unit length.  4-digit readout.  110 volts.
